Product description
Eagle Wireless NSM500DR – High-Performance SBC for AI, Robotics & Industrial Automation
The Eagle Wireless NSM500DR is a versatile single-board computer based on the Qualcomm QCM6490 Octa-Core SoC delivering outstanding performance for modern edge applications. Equipped with a 12 TOPS NPU, Adreno™ 643 GPU and advanced cellular and wireless connectivity, it is ideal for robotics, vision systems, industrial controllers and smart automation devices.
AI Acceleration & Advanced Graphics
With up to 12 TOPS of AI compute, the SBC supports demanding inference workloads such as object detection, tracking, classification, SLAM and more.
Rich Connectivity & Industrial Interfaces
The board provides extensive I/O capabilities required in industrial environments:
- USB, HDMI, eDP, MIPI CSI
- RS232, RS485, CAN
- Ethernet, SIM slot, SD slot
A WiFi-only version without integrated 5G is available.
Operating System Flexibility
- Ubuntu 20.04
- Android 13*
- Windows 11*
Engineered for Industrial Use
Low power consumption, Auto-Power-On, Wake-on-LAN and a Hardware Watchdog ensure stable operation in demanding 24/7 applications.
Typical Applications
- Autonomous mobile robots (AMR/AGV)
- Edge AI & computer vision systems
- Industrial automation & machinery
- Transportation, telematics & fleet systems
- Smart IoT devices & digital signage
Specifications
| Category | Specification |
|---|---|
| Processor | Qualcomm QCM6490, Octa-Core, 1.9–2.7 GHz |
| GPU | Adreno™ 643 GPU |
| AI Performance | 12 TOPS NPU |
| Connectivity | 5G Sub-6, Wi-Fi 6E, Bluetooth 5.2, GNSS (GPS, GLONASS, Galileo, BDS) |
| I/O Interfaces | USB, Ethernet, RS232, RS485, CAN, HDMI, eDP, MIPI CSI, SIM, SD |
| Operating Systems | Ubuntu 20.04, Android 13*, Windows 11* |
| Power Features | Ultra-low power, Auto-Power-On, Wake-on-LAN, Watchdog |
| Dimensions | 120.50 × 106.74 × 22.50 mm |
FAQ – Frequently Asked Questions
FAQ – Frequently Asked Questions
Is the NSM500DR available without 5G?
Yes — a WiFi-only option is available.
What applications benefit from the QCM6490 platform?
Robotics, industrial automation, AI inference, mobile machinery and vision systems.
Does it support Windows 11?
Yes, Windows 11 is supported depending on vendor approval.
How powerful is the AI accelerator?
The built-in NPU delivers up to 12 TOPS for modern AI workloads.
Which GNSS constellations are supported?
GPS, GLONASS, Galileo, BDS and more depending on configuration.
