Product description
WNFQ-261ACNI(BT) is a 802.11ac/a/b/g/n Dual-Band Wi-Fi + Bluetooth M.2 230 module based on Qualcomm Atheros QCA6174A chipset. This highly integrated module supports a wide range of WLAN capabilities with seamless roaming and advanced security for enterprise application. The wireless module complies with IEEE 802.11ac/a/b/g/n 2×2 MIMO. The Bluetooth supports BT 5.0 + HS, BLE and is backwards compatible with BT 1.X, 2.X Enhanced Data Rate. The integrated module provides PCIe Interface for Wi-Fi and USB interface for Bluetooth. The download speeds are 300Mbps on N networks and 867Mbps on AC networks.
Adopting the latest WiFi 5 solution. WNFQ-261ACNI(BT) is ideal for next-generation high throughput enterprise networking and Industrial-graded (-40°C~85°C) solutions. Incorporated with advanced security encryption, such as WEP, WPA, WPA2 and 802.1x, it helps prevent user’s devices from malicious attacks.
Key features
- Chipset: Qualcomm Atheros QCA6174A
- Antenna: 2 x IPEX MHF4 connectors, 2T2R
- Interface: PCIe: WLAN; USB: Bluetooth
- Output Power up to 15 dBm
- OS Support: Win7/8.1/10, Linux (Open Source), Recommend Kernel v4.0+
