Modular Vision 10.1 MX95 HMI Panel – Seco SF-E88-MDV-1321-1000-C0

The Seco Modular Vision 10.1 MX95, manufacturer part number SF-E88-MDV-1321-1000-C0, is an industrial 10.1-inch HMI touch panel based on the NXP i.MX95 applications processor with 4 GB LPDDR5 RAM and 16 GB eMMC storage.

Modular Vision 10.1 MX95 overview

The panel combines a projected-capacitive 10.1-inch touchscreen with 1280 x 800 pixel resolution and a brightness of at least 400 nits with an IP66-protected front for installation in control cabinets, machine fronts and operator panels. The pre-installed Clea OS, based on Yocto Linux, provides secure boot, OTA updates and device monitoring.

Configuration & Features

• NXP i.MX95: 6x Arm Cortex-A55 at 1.8 GHz, 1x Cortex-M33 at 333 MHz, 1x Cortex-M7 at 800 MHz; Arm Mali-G310 V2 GPU with 2D/3D acceleration
• 4 GB LPDDR5-6400 memory (2 channels, 32-bit) and 16 GB eMMC 5.1 as boot storage, plus a micro SD card slot on the carrier board
• 10.1-inch P-Cap touch display, 1280 x 800 pixels, ≥400 nits, ≥30,000 hours backlight lifetime, LVDS interface
• Interfaces: 1x Gigabit Ethernet (RJ45), USB 3.1, USB 2.0, USB Type-C, USB Type-A, 2x RS232, 1x RS485, 1x CAN, I²C, SPI, plus 2x digital I/O via a 20-pin JST SHD 1.0 connector
• IP66 front protection, chemically strengthened cover glass, operating temperature range 0 to 60 °C
• Wide-range 9 to 32 VDC power supply, mono speaker output up to 3 W RMS
• Dimensions 270.1 x 187.1 x 51.7 mm

Typical applications

The Modular Vision 10.1 MX95 fits operator panels for industrial panel and HMI integration as well as rugged industrial touch displays for machine and plant fronts with edge AI requirements.

Note on procurement

According to the manufacturer, the Modular Vision 10.1 MX95 is distributed through authorized distribution; availability and pricing may vary by region. For design-in support, samples and project pricing on this variant, contact Atlantik Elektronik.
