Modular Vision 10.1 MX95 HMI Touch Panel – Seco SF-E88-MDV-1211-1000-C0

The Modular Vision 10.1 MX95 is an industrial HMI touch panel from SECO with manufacturer part number SF-E88-MDV-1211-1000-C0, built on the NXP i.MX95 processor with 8 GB RAM and 32 GB eMMC storage.

Modular Vision 10.1 MX95 Overview

Powered by NXP i.MX95, the Modular Vision 10.1 MX95 is a ready-to-integrate industrial HMI, built for projects that need a stable, deployable solution from the start. The platform integrates Clea OS, enabling secure remote management and fast deployment through standard industrial interfaces, including Ethernet, RS232, RS485, CAN, USB, and digital I/O.

Configuration & Features

• 10.1-inch Capacitive Touch (P-Cap) display with 1280 × 800 resolution and ≥400 nits brightness over an LVDS interface
• Six Cortex-A55 cores running at 1.8 GHz plus a dedicated Cortex-M33 and Cortex-M7 core within the NXP i.MX95 processor
• Arm Mali-G310 GPU with an integrated NPU for on-device AI acceleration
• 8 GB LPDDR5 RAM and 32 GB eMMC storage for this variant (per the official manufacturer price list)
• IP66 front protection, resistant to dust and splashes
• Operating temperature range of 0 to 60 °C with a wide DC input for industrial power systems
• Pre-installed Clea OS with built-in security, monitoring, and update mechanisms

Typical Applications

The panel suits industrial control and visualization tasks with edge AI support, including manufacturing, plant monitoring, and building or access-control systems. Related products can be found under Touch Displays and solution approaches under Industrial Panels, Tablets & HMI.

Note for Procurement

According to the manufacturer, the module ships without a power supply. It is a recently introduced product within the Modular Vision series; availability and lead times may vary by region. For current availability, samples, and project pricing, please contact our sales team.
